Invacare TDX 2P2 Narrow Base - PRESCRIBED CHAIR (MADE TO MEASURE)

TDX SP2 NB is stylish and durable powerchair with excellent performance. It is packed with a wide range of seating options for optimum comfort and support. This makes the TDX SP2 NB the powerchair for individuals who need full functionality, but do not want to compromise on style.

TDX SP2 NB is carefully designed to enhance stability and safety. It has a stability lock function that ensures all six wheels stay solidly on the ground even on uneven terrain. The patented SureStep suspension technology enables a smooth ride while negotiating challenging surfaces.

The Invacare TDX SP2 NB offers an intuitive driving experience. It is equipped with a Centre Wheel Drive –this outstanding wheelbase provides excellent manoeuvrability and intuitive driving experience.

LiNX Smart Technology is another notable feature of the TDX SP2 NB. The Invacare LiNX is our insight inspired control system with advanced technology that provides a superb driving experience for users. It also allows professionals to configure and tailor powerchairs fast and more intuitively. The smart control system enables programming and maintenance updates to be made wirelessly and in real-time. More so, it has straightforward access to statistical and diagnostic information, thus giving complete visibility to professionals. Below are some key features:

• Proton head array: It comes with an adjustable headrest with three proximity sensors and in-built Bluetooth.

• Compact remote with LED display: Ideal for users who have a limited range of motion and reduced strength.

• IDC dual control: This feature enables access to the drive function, controlled by a speed handle with emergency stop feature.

• Attendant control unit: This feature enables carer to have access to certain chair functions.

• Touchscreen technology: It comes with REM400 remote that has an impressive 3.5” colour touchscreen – it requires minimal force to operate. This brings modern technology to the powerchair market; this innovative interactive remote can be configured to a users’ physical and cognitive ability.

• Built-in Bluetooth: With the REM400, users can connect to 3 devices at the same time, and it has mouse mover technology.

• SEAT WIDTH

  380 - 530 mm



  SEAT DEPTH

  410 - 510 mm 510 - 560 mm



  SEAT HEIGHT

  450 / 475 mm 475 - 775 mm



  BACKREST HEIGHT

  480, 540, 560 mm



  ARMREST HEIGHT

  245 - 310 mm



  LENGTH OF FOOTRESTS

  290 - 460 mm



  SEAT ANGLE

  0 - 20° / 0 - 30°



  BACKREST ANGLE

  90° - 120°



  TOTAL HEIGHT

  1010 - 1170 mm



  TOTAL LENGTH WITHOUT FOOTRESTS

  980 mm



  DRIVING UNIT WIDTH

  610 mm



  TOTAL LENGTH

  1160 mm



  MAX. USER WEIGHT

  150 kg



  BATTERY CAPACITY

  50 Ah



  TURNING DIAMETER

  1120 mm



  MAX. CLIMBABLE OBSTACLE HEIGHT

  75 mm



  MAX. SAFE SLOPE

  9° / 16 %



  MOTOR CAPACITY

  2 x 324 W



  SPEED

  6 and 10 km/h



  DRIVING RANGE

  up to 26 km



  TOTAL WEIGHT

  138 kg



  CRASH TESTED



  RIM COLOUR

  Island Blue, Lights Out Matte - Black, RockStar Red, SpaceStation Silver,  Invacare Blue, Wet Black, Grape JellyBean



  SHROUD COLOUR

  Island Blue, Lights Out Matte - Black, RockStar Red, SpaceStation Silver,  Invacare Blue, Wet Black, Grape JellyBean

  COMMENT

  1. Seat cushion 430 mm 2. Additional 100 mm by armrest adjustment 3. Extended profile rail package for larger seat depth 4. Ground to seat plate without cushion 5. With seat lifter or powered tilt 6. With lifter 7. Measured from seat plate 8. Mesured from footplate to seat plate 9. Depending on seat position 10. Width of wheelbase 11. Depending on configuration 12. Measurement with 73.5 Ah batteries according to ISO 7176-4 @ 6 km/h, driving range will vary by configuration (battery size, speed) 13. Invacare Modulite™ seat components are cross compatible across the Invacare power wheelchair range and partly with the Invacare Rea® family. 14. 12 km/h DuraWatt motors
